Product Description:

The COG LCD Module is a versatile and high-performance character LCD module that offers a clear and crisp display. It is a COG dot matrix LCD module with a COG (Chip On Glass) structure, which means the driver IC is directly mounted on the glass substrate, making it compact and easy to integrate into various applications.

The COG LCD Module features a COG+FPC (Chip On Glass + Flexible Printed Circuit) connector, which allows for a secure and reliable connection between the module and the controller board. This connector also enables a compact and space-saving design, making it suitable for various compact devices and applications.

The LCD driving voltage of the COG LCD Module is 10.5V, providing a stable and efficient power supply for the module. This ensures a consistent and reliable performance, allowing for a clear and high-quality display.

The COG LCD Module is equipped with the ST7567A LCD controller, which is a highly efficient and versatile controller. It supports various display modes and features, allowing for a customizable and flexible display. It also has a built-in power-saving mode, which helps to reduce power consumption and prolong the lifespan of the module.

The COG LCD Module has a display resolution of 128x32, providing a large and clear display area for characters and graphics. This allows for a wide range of information and content to be displayed, making it suitable for various applications, such as industrial equipment, medical devices, and consumer electronics.

The COG LCD Module offers three different polarizer modes: transmissive, transparent, and reflective. The transmissive mode provides a clear and bright display, making it suitable for indoor use. The transparent mode allows for a transparent display, making it suitable for applications that require the display to be hidden when not in use. The reflective mode provides a clear display even under bright sunlight, making it suitable for outdoor use.

The COG LCD Module is a reliable and versatile character LCD module with a COG dot matrix structure. It offers a compact and space-saving design, a stable and efficient power supply, a highly efficient LCD controller, and a customizable display. With its various polarizer modes, it is suitable for a wide range of applications, making it an ideal choice for any project that requires a high-quality character display panel.

Features:

• Product Name: COG LCD Module
• Operation Voltage: 0-5.5
• Connector: COG+FPC
• Power Supply Voltage: 3.0v
• Show Contents: 128x32
• Lcd Driving Voltage: 10.5V
• COG Character LCD Display Unit
• Mono Character Display Module
• Character LCD Module
• Built-in Controller
• High Contrast Ratio

Technical Parameters:

Applications:

Brand Name: LCD Mall

Model Number: Customized

Place of Origin: GUA, CN

Interface Mode: MCU/8bit

Polarizer Mode: Transmissive/Transparent/Reflective

Supplier Type: OEM and ODM

Structure: COG

Viewing Direction: 6:00

The COG LCD Module, also known as the COG Character LCD Screen, is a type of display module used for various electronic devices. It is a mono character display module that can also be used as a graphic LCD module. This product is manufactured by LCD Mall, a trusted brand in the electronic industry.

The COG LCD Module is suitable for a wide range of applications in different industries. Its compact size and easy interface make it a popular choice for various electronic devices. Some of the common applications and scenes where this product is used are:

• Medical devices: The COG LCD Module is widely used in medical devices such as blood pressure monitors, pulse oximeters, and patient monitors. Its high-resolution display and accuracy make it suitable for medical applications.
• Automotive industry: In the automotive industry, this product is used in car audio systems, dashboard displays, and navigation systems. Its durability and reliability make it suitable for use in a rough environment.
• Industrial equipment: The COG LCD Module is also used in industrial equipment such as control panels, sensors, and measurement devices. Its clear display and easy interface make it ideal for industrial applications.
• Consumer electronics: From washing machines to smart home devices, the COG LCD Module is widely used in various consumer electronics. Its compact size, low power consumption, and high-resolution display make it a popular choice among manufacturers.
• Educational devices: This product is also used in educational devices such as calculators, electronic dictionaries, and language translators. Its clear display and easy interface make it suitable for educational purposes.

Overall, the COG LCD Module can be used in any device that requires a compact, high-resolution, and easy-to-use display. Its versatile nature makes it a suitable choice for various industries and applications.

Customization:

COG LCD Module, also known as Chip On Glass LCD Module, is a type of display module that uses a COG packaging method to mount the driver IC directly onto the glass substrate, making it compact and lightweight. This type of LCD module is commonly used in various electronic devices such as digital cameras, smartphones, and handheld devices.

At LCD Mall, we offer customized COG Dot Matrix LCD Modules and COG Character Graphic LCD Panels to meet the specific requirements of our clients. Our customization service includes OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) options, allowing you to choose the best solution for your business needs.

With our in-house R&D team and advanced production facilities, we are able to provide customized designs for our clients. Our customization options include:

• Customized LCD display size
• Customized LCD driving voltage
• Customized module size
• Customized power supply voltage
• Customized dimensions
• And more

As a leading manufacturer and supplier of LCD modules, we pride ourselves on providing high quality and reliable performance products. Our team is dedicated to understanding your unique requirements and providing you with the best solutions to meet your business needs. With our customization service, you can ensure that your LCD modules are tailored to your specific requirements.

For more information about our COG LCD Module customization service, please contact us.

Packing and Shipping:

Our COG LCD Module is carefully packaged to ensure safe delivery to our customers. The packaging includes:

• Anti-static bag for protection against electrostatic discharge
• Foam padding for shock absorption
• Strong cardboard box for structural support
• Outer layer of bubble wrap for additional protection

We also offer customized packaging options for bulk orders, including pallets and crates for secure transportation.

For shipping, we partner with reputable logistics companies to ensure timely and efficient delivery to our customers worldwide. We offer various shipping options, including air, sea, and land transportation, to meet the specific needs of our customers.

Upon shipment, our customers will receive a tracking number to monitor the delivery status of their order.

At COG LCD Module, we prioritize the safety and satisfaction of our customers, and our packaging and shipping processes reflect that commitment.

FAQ:

• Q: What is the brand name of this product?

  A: The brand name of this product is LCD Mall.

• Q: What is the model number of this product?

  A: The model number of this product is Customized.

• Q: Where is this product manufactured?

  A: This product is manufactured in GUA,CN (Guangdong, China).

• Q: What is a COG LCD module?

  A: A COG (Chip-On-Glass) LCD module is a display technology where the driver IC is directly mounted onto the glass substrate of the LCD, resulting in a compact and thin design.

• Q: What are the advantages of using a COG LCD module?

  A: Some advantages of using a COG LCD module include a thinner and more compact design, lower power consumption, and higher reliability due to fewer connections between the driver IC and the display.
