Product Description:

The Serial Port Screen is designed to work with a range of devices, making it a versatile display option. It comes with a CTP VCC=IOVCC: 2.8V-3.3V, which makes it compatible with a wide range of systems with different voltage requirements. The CTP transmittance of the screen is ≥86％, ensuring clear and crisp images.

The Serial Port Screen is built with a double-layer PCBA, which enhances its durability and reliability. The double-layer design also helps to prevent interference from other components, ensuring that the screen provides clear and accurate images at all times.

The TFT LCM Panel used in the Serial Port Screen is of the highest quality, providing exceptional performance and longevity. The TFT LCD Screen is designed to withstand heavy use and is ideal for use in a wide range of settings, including industrial and commercial applications.

The Serial Port Screen is easy to install and operate, making it an ideal choice for users who need a high-quality display that is easy to set up and use. Whether you're looking for a display for your home, office, or industrial facility, the Serial Port Screen is an excellent choice.

Features:

• Product Name: Serial Port Screen
• LCD Display: TFT LCD Modules
• LCM Backlight: 12 Chip White LED, 6S2P VF =18.6±1.2V; IF = 40mA
• LCM Size: 5.0 Inch
• LCM Interface: SPI Interface
• CTP Touch Points: Multi-touch
• LCM Touchscreen: No
• Keywords: LCD Screen

Technical Parameters:

This product features a 5-inch WVGA TFT LCD screen, also known as a liquid crystal display panel. It has a surface luminance of 400cd/m2 (TYP) and is driven by an LT7381 driver IC. The PCBA flatness is ≥85%, and it uses an SPI interface with 20 pins. The CTP VCC=IOVCC is 2.8V-3.3V, and the PCBA structure is made of gold, cuprum, and FP4. The LCM part number is LMT050WV008C-PZ015.

Applications:

The Serial Port Screen (model number LMT050WV008C-PZ015-DC010) is a high-quality LCD screen that is suitable for a wide range of applications. This product is made in Guangzhou, China and has passed rigorous quality control tests to obtain ISO9000, CE and ROHS certifications.

The Serial Port Screen is an ideal choice for those who are looking for a reliable and durable LCD display. It has a minimum order quantity of 500pcs and its price depends on the quantity ordered. The packaging details are international standard packaging, and delivery time is typically 2-5 weeks. Payment terms include T/T, West Union, Credit and Paypal, and the supply ability is 1000000/month.

The Serial Port Screen features a CTP COF/IC of GT911 and an interface of IIC, with an IC address of 0X5D/0X14. The PCBA structure is made of gold, cuprum and FP4, and the LCM interface is SPI interface. The CTP cover glass is made of white glass, and CTP VCC=IOVCC is 2.8V-3.3V.

The Serial Port Screen is suitable for various occasions and scenarios. It can be used for industrial control, medical equipment, POS machines, handheld devices, and more. It is also ideal for automotive applications, including car audio systems, navigation systems, and dashboard displays.

The Serial Port Screen is a high-quality liquid crystal display that offers superior image quality and durability. It is easy to use and is an ideal choice for those who require a reliable and long-lasting display solution.
