Product Description:

The Medical TFT Display is a high-quality, state-of-the-art display designed specifically for medical equipment. It is equipped with advanced features and specifications that make it ideal for use in various medical devices, providing clear and accurate visual representation.

• IPS TFT LCD Display
• High Brightness TFT LCD Module
• HDMI TFT LCD Display

The Medical TFT Display has been designed and manufactured to meet the specific needs and requirements of the medical industry. It offers superior image quality, exceptional resolution, and advanced features that make it stand out among other displays in the market.

The Medical TFT Display boasts a resolution of 268RGB*800, providing a sharp and clear display for medical professionals to view and analyze medical data and images.

The Medical TFT Display has a wide operating temperature range of -20°C to +70°C, making it suitable for use in various medical environments without compromising its performance.

The display is equipped with 6 Chip White LEDs and a 4P FPC Connector, with a VF (forward voltage) of 18.0-19.2V and an IF (forward current) of 20mA. This ensures a bright and consistent backlight for accurate display of medical images and data.

The Medical TFT Display is designed with a MIPI interface, providing high-speed data transfer and compatibility with various medical devices and systems.

The display has a general tolerance of +/-0.2mm, ensuring precise and accurate positioning for optimal display performance.

With its advanced features and specifications, the Medical TFT Display is a reliable and high-quality display solution for medical equipment. It is a crucial component in ensuring accurate and efficient diagnosis and treatment in the medical field.

Features:

• Product Name: LCD Mall 300 brightness 268*RGB*800 resolution MIPI interface 2.98 inch TFT IPS full view TFT LCD Display
• Operating Temp: -20°C ~ +70°C
• Driver IC: ST7701S
• Backlight: 6 Chip White LEDs, 4P FPC Connector VF =18.0-19.2V; IF = 20mA
• General Tolerance: +/-0.2mm
• Viewing Direction: ALL/IPS
• Screen Size: 2.98 Inch TFT LCD
• Bar Type:strip TFT LCD

Technical Parameters:

Applications:

LCD Mall's Medical TFT Display, model number LMT030WV001C-SN, is a high-quality display designed for medical applications. With its IPS TFT LCD display and HDMI interface, it provides clear and accurate images, making it an essential tool for medical professionals.

• Driver IC: ST7701S
• Viewing Direction: ALL/IPS
• Display Type: 2.98 Inch TFT / Transmissive
• Backlight: 6 Chip White LEDs, 4P FPC Connector VF = 18.0-19.2V; IF = 20mA
• Operating Temperature: -20°C ~ +70°C

The Medical TFT Display from LCD Mall is suitable for various medical scenarios, such as:

• Hospital operating rooms - providing clear and accurate images for surgeons during procedures
• Medical training facilities - allowing students to view detailed medical images for learning purposes
• Diagnostic equipment - displaying medical images and results for accurate diagnosis
• Patient monitoring systems - providing real-time monitoring of patient vitals and medical data
• Medical research - displaying detailed images for analysis and research purposes

There are several reasons why LCD Mall's Medical TFT Display stands out from other products in the market:

• High-quality IPS TFT LCD display for accurate and clear images
• HDMI interface for easy connectivity and compatibility with various medical devices
• Wide operating temperature range of -20°C to +70°C for reliable performance in various environments
• Certified by ISO9000, CE, and ROHS for quality and safety assurance
• International standard packaging for safe and secure delivery
• Fast delivery time of 2~5 weeks to meet urgent medical needs
• Flexible payment terms including T/T, West Union, Credit, and Paypal
• High supply ability of 1000000/month to meet high volume demands
• Compact and lightweight design for easy installation and use

In conclusion, LCD Mall's Medical TFT Display, with its superior features and reliability, is the perfect choice for medical professionals and institutions looking for a high-quality and efficient display for medical applications.

Customization:

Packing and Shipping:

Our Medical TFT Display is carefully packaged to ensure safe delivery to your location. The following steps are taken to ensure the product arrives in perfect condition:

• The display is first wrapped in protective foam to prevent any damage during transportation.
• It is then placed in a sturdy cardboard box, specifically designed for the display's size and shape.
• The box is sealed with high-quality packing tape to prevent any tampering or damage.
• A Fragile sticker is placed on the box to alert handlers to handle with care.
• The boxed display is then placed in a larger shipping box with additional cushioning to provide extra protection.
• The shipping box is sealed with heavy-duty tape and labeled with the necessary shipping information.
• For international shipments, the display is also protected with waterproof wrapping to ensure safe delivery.

Once the Medical TFT Display is packaged, it is ready for shipping. We work with trusted and reliable shipping carriers to ensure timely and secure delivery of your product. Our standard shipping method is ground shipping, but expedited shipping options are also available for urgent orders.

Our team carefully tracks and monitors the shipment to provide updates on its location and estimated delivery date. Upon arrival at your location, please inspect the package for any signs of damage during transit. If any issues are found, please contact us immediately for assistance.

Thank you for choosing our Medical TFT Display. We are committed to providing a high-quality product and ensuring its safe delivery to your doorstep.

FAQ:

• Q: What brand is the Medical TFT Display?
  A: The brand of this display is LCD Mall.
• Q: What is the model number of this display?
  A: The model number is LMT030WV001C-SN.
• Q: Where is this display manufactured?
  A: It is manufactured in GUA, CN.
• Q: What certifications does this display have?
  A: This display is certified with ISO9000, CE, and ROHS.
• Q: What is the minimum order quantity for this display?
  A: The minimum order quantity is 1 piece.
• Q: How is this display packaged?
  A: It is packaged using international standard packaging.
• Q: How long is the delivery time for this display?
  A: The delivery time is 2~5 weeks.
• Q: What are the payment terms for this display?
  A: The payment terms include T/T, West Union, Credit, and Paypal.
• Q: What is the supply ability for this display?
  A: The supply ability is 1000000 pieces per month.
